Pocketbook Era lockscreen / standby image

[Valwit]

Originally Posted by Cyfranek

Thank you @kaznelson and @Jungleham for your tips. I wrote a manual for Polish users and my blog readers: http://cyfranek.booklikes.com/post/5...kow-pocketbook

works for versa pro too, 1072 × 1448

[switch emulator]

Thanks for the instructions! I encountered a minor issue with my files that prevented them from showing up. For troubleshooting:

I created the images in Canva, exported them as PNGs, and then used an online BMP converter, but my PB didn’t recognize these images. The problem was resolved by opening the images in GIMP 2.0, exporting them as BMPs, and selecting 24-bit under the advanced options. I hope this helps someone!

One more question: When viewing in dark mode, the image appears inverted. Is there a way to prevent this, or can I add a version of the image specifically designed for dark mode?

[MJV]

Thank you for all your inputs re: customizing the lockscreen (sleep mode). After playing a bit I finally managed to set it to my tastes.

[raiderkilo]

Originally Posted by MJV

Thank you for all your inputs re: customizing the lockscreen (sleep mode). After playing a bit I finally managed to set it to my tastes.

Please, can you share the picture

[panda_coin]

Originally Posted by kaznelson

...but they work.


/system/resources/Line/taskmgr_lock_background.bmp
/system/resources/Line/taskmgr_lock_background_landscape.bmp

I have an issue where taskmgr_lock_background.bmp gets overwritten with whatever book's cover i open. Been trying to use these sample images from kaz, but keep hitting this issue. Anybody else dealt with this? Using a pocketbook era.

[Tintenfisch]

Did anyone get it to work on the newest Software? (Pocketbook Era). It does not work with newest update?

I did the files with

• • right dimensions 1264 x 1680 px (and reverse for landscape)
  • right background color #808040
  • 24 bit saved as BMP
  • saved horizontal + landscape in the right names & folders (see screenshot)

Still it shows the stock sleep image?

See screenshot:

[Moonbase59]

Just tried, works here on FW U700.6.8.4183.

Since we have so few "ready-made" images, I’m adding the one I currently use on my Pocketbook Era, a sleeping cat.

@Tintenfisch: Would you share your sleeping cat? I quite like that, too.

Re your question: Didn’t try 24-bit, I saved mine as indexed 16-color, this reduces filesize from 6.4 MB to 1.1 MB.

$ file taskmgr_lock_background.bmp
taskmgr_lock_background.bmp: PC bitmap, Windows 98/2000 and newer format, 1264 x 1680 x 4, cbSize 1061962, bits offset 202

[neil_swann80]

Here's the one I made for my HD3, 1072x1448...

[Moonbase59]

I put a few of my lockscreen images here.
