Native Kindle Menu for Paperwhite (1 & 2) and Touch

[twobob]

fine. That one will do the job. might look like crap on the touch. cant remember ^^

[Aeris]

Originally Posted by twobob

fine. That one will do the job. might look like crap on the touch. cant remember ^^

Hope not eheh... don't even know if baf has got a PW

[piperclassique]

You lot are real stars!

[thomass]

Originally Posted by twobob

fine. That one will do the job. might look like crap on the touch. cant remember ^^

Originally Posted by Aeris

Hope not eheh...

Galculator in Kindle Menu 0.7 is fine on the Touch, thanks.

[chr1st0ph3rc]

Mine doesn't show up in kual. Works from kterm though.

[thomass]

Originally Posted by chr1st0ph3rc

Mine doesn't show up in kual. Works from kterm though.

I used it via Kindle Menu (see the first post of this thread)

[twobob]

Originally Posted by chr1st0ph3rc

Mine doesn't show up in kual. Works from kterm though.

"your" what?

The galculator? the menu? I'm lost...

[soulafein]

Is it possible to include HackedUpReader shortcut in next release?

[Aeris]

Originally Posted by soulafein

Is it possible to include HackedUpReader shortcut in next release?

I'd prefer to keep Kindle Menu only for exetensions stuff (not things that are installable through .bin), and to keep only one shortcut for the best app for each task... Did you try KOreader to see if it lets you do the same things that HackedUpReader does?

P.S. from HackedUpReader thread:

Other reading software for the Kindle Touch and Paperwhite that are using the Cool Reader engine and therefore have at least the same format support as HackedUpReader are:

KOReader (formerly known as KindlePDFViewer)
CoolReader 3 on Kindle (using a QT-interface that is IMO unfortunately not well suited for a touch screen)

[Aeris]

Being similar questions asked from Gorazd too, I'll answer here:

I didn't understand if is your graphic menu for your apps only or can be costumized. Can I use your Kindle Menu v. 0.7 for all my apps or not?

Theoretically: yes. You could add by hand the code to make your apps run even if they are not listed by default in Kindle Menu.

How is this menu working? How do you start graphic menu? Via standard kual menu?

Yes, there is a kual menu entry to launch it, but you could launch it also from kterm. If you enable the android-like shortcut (always from KUAL), you could open the menu simply swiping from the topbar, like on android.

Kindle Menu is basically an html page, loaded by the script in /extensions/kindlemenu/bin/kindlemenu.sh file:

#!/bin/sh

lipc-set-prop com.lab126.pillow customDialog '{"name": "../../../../mnt/us/extensions/kindlemenu/bin/kindlemenupage", "clientParams": {"dismiss": true}}'

The command simply "tells" to the system to draw the html page placed in the folder /extensions/kindlemenu/bin/kindlemenupage (.html must be omitted in the path).
Due to "dismiss: true" parameter, if the script is started twice, the windows is dismissed instead of shown. You can't run every type of html files this way: your file must contain some special code, that you can easily spot opening the simpler html file in /extensions/kindlemenu/bin/html/calendar.html

Can brick kindle paperwhite if you miss something in this custom graphic design.

Normally, not. If the html page contains some error, it will simply display that error, or in the worse case won't show at all. Being that the html page, through nativeBridge command, can execute custom code, if that code is malicious you could brick your device. But this would happen for every KUAL entry too, or typing the code directly in kterm or via USBNetwork.

Now, a little guide to add custom app entries:

GUIDE: How to add your custom app launcher to Kindle Menu

NOTICE: THE FOLLOWING GUIDE HAS BECOME OBSOLETE SINCE THE RELEASE OF KINDLE MENU V.1.4. PLEASE UPDATE YOUR APP AND REFER TO THE FIRST POST OF THIS THREAD FOR THE NEW, FASTER METHODS TO ADD CUSTOM SHORCUTS

Spoiler:

1. Open the file /extensions/kindlemenu/bin/kindlemenupage.html with your favourite text editor
2. Find the text

   // ### APP LAUNCHERS FUNCTIONS ###

3. Just below, add a new function, similar to the ones that you already see there, in the following way:
   (For this demonstration, we'll call it SampleAPP)


   function SampleAPP(){
   nativeBridge.dismissMe();
   killallprocesses();
   nativeBridge.setLipcProperty( "com.lab126.system", "sendEvent", "; sh -c 'DISPLAY=:0 your_launch_code_goes_here'");
   }

4. In the above code, you must replace your_launch_code_goes_here with your app launching script. To spot what it is, you must go in your app folder under "extensions" one, and open the file menu.json. In our sample, it will be something like:

   /mnt/us/extensions/SampleAPP/menu.json

   The launch code will look something like: /mnt/us/extensions/SampleAPP/bin/sample_app_launch.sh

5. Your launch script function is now ready. You need only to add the app icon/link. Again, in the file kindlemenupage.html, search for the code:


   <div id="appContainer">

   Just below, past this code:


   <div class="appOuter" onclick="SampleAPP()" >
   	<div class="appIcon" style="background-image:url('icons/SampleAPP_icon.jpg');" ></div>
   	<div class="appName">SampleAPP_link_name</div>
   </div>

Where SampleAPP_icon.jpg is the name of the icon image you have prepared in KindleMenu icons subfolder. If you don't have any icon yet, don't worry, the image just won't show, but the app link will work anyway.
Replace SampleAPP_link_name with the link you want to be shown in Kindle Menu.

If you did everything well, the new app linkshould be now visible and working!

IMPORTANT: remember that updating Kindle Menu to any new version will overwrite your changes to kindlemenupage.html, hence removing your customized launchers. Do a backup of the added lines before updating, and set back the changes right after.

[soulafein]

Originally Posted by Aeris

I'd prefer to keep Kindle Menu only for exetensions stuff (not things that are installable through .bin), and to keep only one shortcut for the best app for each task... Did you try KOreader to see if it lets you do the same things that HackedUpReader does?

P.S. from HackedUpReader thread:

Yes, I tried but it has lack of functions that I think is important for epub files (e.g. page margins, font size). Anyway, thanks. Your app is really cool

[twobob]

Originally Posted by soulafein

Yes, I tried but it has lack of functions that I think is important for epub files (e.g. page margins, font size). Anyway, thanks. Your app is really cool

???

Click at the BOTTOM of the screen. what it lacks is you reading the instructions :P

[Aeris]

Big update coming soon... stay tuned!

[ladykayaker]

Originally Posted by Aeris

Just extract everything inside the .zip archives into your kindle main directory. To launch it use the provided KUAL entries.

What do you mean by launch using the provided KUAL entries?

[bhaak]

Originally Posted by twobob

Click at the BOTTOM of the screen. what it lacks is you reading the instructions :P

The last version of KOreader that I tried was v2013.03-545-g2044f5a and I couldn't exactly reproduce the display of HackedUpReader with KOreader on my Kindle Touch. But I think this was due to the fact that HackedUpReader exposes more of the options to fine-tune the different settings (for example the margins) than KOreader does (and I'm a bit anal about how my epubs are rendered).

For my usage patterns, the touch zones of HackedUpReader suit me better (surprise, surprise, that's why I coded them that way ). I guess they are not configurable in KOreader?
