100% DIY Kindle External Keyboard

CapitainDerya · 08-08-2013, 09:03 AM

Just Look at Attached image

twobob · 08-08-2013, 09:05 AM

interesting concept

CapitainDerya · 08-08-2013, 09:12 AM

is it clear and applicable

knc1 · 08-08-2013, 09:13 AM

That is a device called a "chorded keyboard" been around for decades.

Some background:
http://trevors-trinkets.blogspot.com...keyboards.html

But the idea of using the existing 5-way button on the device, that is a good one.

Other 5-finger keyboards:
http://www.google.com/search?q=five+...w=1099&bih=805

@twobob: If you can play a hit song with only six strings on the guitar, you should be able to write award winning code with only five keyboard keys.

CapitainDerya · 08-08-2013, 09:46 AM

I havent seen this 5 key gatget, thanks knc1

ixtab · 08-08-2013, 10:23 AM

@knc1: There's one button missing: http://www.thisiswhyimbroke.com/keyboard-panic-button . I have one of these one my keyboard

knc1 · 08-08-2013, 10:26 AM

Quote:

Originally Posted by ixtab

@knc1: There's one button missing: http://www.thisiswhyimbroke.com/keyboard-panic-button . I have one of these one my keyboard

That page banner is (or should be) an award winner!

knc1 · 08-08-2013, 10:48 AM

Quote:

Originally Posted by CapitainDerya

I havent seen this 5 key gatget, thanks knc1

It is a good idea.

There are nine buttons along the bottom of the K4 if we count the two to the left and right of the 5-way.

So this should take care of the complaints that the K4 doesn't have enough buttons.

It will probably take a good bit of research to discover how to intercept all of the button events so that they can be translated into a full keyboard - but it should be possible.

hawhill · 08-08-2013, 11:08 AM

Weeeeell, 2^4 is 16, which is arguably not enough for the alphabet, and we should rule out the case where all switches are in 0 position to keep this case for "no key pressed". That said, I'm not sure whether the 4-way isn't just realized as a 2x2 matrix internally rather than 4 switches.

All that said, it somehow sounds a tad bit more viable to just hook up a USB-OTG capable microcontroller in USB serial host mode to the USB port. This also has the charme of not interfering with existing functionality... Hmmm... on my shelf, there's a PIC32MX220 test board waiting for some spare time and dedication...

ben.sawyer · 02-28-2017, 07:56 PM

Quote:

Originally Posted by knc1

That page banner is (or should be) an award winner!

hahahaah I love it!
PANIC button, especially useful with blue screen of death

edit: I have found awesome "keyboard" on Geekwrapped for only $69.99 Give me that caps lock, I'm hungry lol
