K3 One more terminal emulator for kindle.

[twobob]

Originally Posted by PoP

to no avail

Spoiler:

[root@kindle myts]# ./myts
Segmentation fault

I didn't try any harder. Files attached for the next one to carry the torch:

Spoiler:

0000:F0F0F0F0C030C030C030000000000000C030C030C030C030000000000000C030C030C030F0F0F0F0
0001:030007800FC01FE03FF07FF8FFFCFFFC7FF83FF01FE00FC007800300
0002:AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555AAAA5555
0003:C300C300C300FF00FF00C300C300C300C3000000000007F807F800C000C000C000C000C000C000C0
0004:FF00FF00C000C000FC00FC00C000C000C0000000000007F807F80600060007E007E0060006000600
0005:7E00FF00C300C000C000C000C300FF007E000000000007F007F80618061807F007C006E006700638
0006:C000C000C000C000C000C000C000FF00FF000000000007F807F80600060007E007E0060006000600
0007:7EFFC3C3C3C3FF7E
0008:06000600060006000600FFF0FFF00600060006000600060000000000FFF0FFF0
0009:C300C300E300F300DB00CF00C700C300C30000000000060006000600060006000600060007F807F8
000A:C300C300C300C300C300C30066003C0018000000000007F807F800C000C000C000C000C000C000C0
000B:018001800180018001800180018001800180018001800180018001800180FF80FF80
000C:FF80FF80018001800180018001800180018001800180018001800180018001800180
000D:FF80FF80C000C000C000C000C000C000C000C000C000C000C000C000C000C000C000
000E:C000C000C000C000C000C000C000C000C000C000C000C000C000C000C000FF80FF80

The issue appears to be uneven length output from the perl script.
Perhaps the script itself has a height/width restriction (I should read it and check I suppose but IIRC it was a few lines at most) which leads me onto thought two. The bdf is wrong : (

FULL DISCLOSURE:

Spoiler:

I had a real struggle to find something that purported to be of the right size, I am a complete novice at these fonts and have spent much time attempting to cram the glyph format stuff in my brain. To limited avail. I attempted what you did with the perl script with the c version on the bdf with similar results. I should have mentioned that pop I am sorry I thought perhaps it was the toolset.

Easiest routes would be a) check the bdf is not garbage with a validator - I am not aware of one off hand

b) get another bdf and try that. I opt for this one myself. I searched for about two days on and off before I dredged up the 12x24 one and the 16x32 is part of the terminus project but IIRC they don´t supply a native bdf.

Fondu? or similar... may be our friend here? It converts quite a few bits and have toyed with it locally to get a feel for it´s abilities but again it´s not something I can ´just do´.

It would be nice to get a huge font. If only for the accessibility of it. Also it is there to be done. What more reason is there?

[PoP]

The .bdf font appears to be quite valid:


As you pointed out, the perl script produces uneven length definitions of the glyphs (hence faithfully recoding the input -- this is *not* incorrect IMHO).

It is the myts code that appears to only expect even lengths. Probably easier to tediously recode the source bdf using fixed 16x32 bitmaps.

[twobob]

sigh. ah. perhaps a simple padding script might do the job. or as you say just make one.

Harrumph. ; ) Thanks for the efforts pop

[PoP]

Originally Posted by twobob

sigh. ah. perhaps a simple padding script might do the job. or as you say just make one.

Harrumph. ; ) Thanks for the efforts pop

I was too lazy to make one, so I found this one. This font is overkill having too many unnecessary glyphs but its insanely big 16x32 pixels provide a 37x25 terminal window. Most importantly the glyphs have fixed width for easy integration in myts.

Enjoy, and thanks for the karma!

[twobob]

Originally Posted by PoP

I was too lazy to make one, so I found this one. This font is overkill having too many unnecessary glyphs but its insanely big 16x32 pixels provide a 37x25 terminal window. Most importantly the glyphs have fixed width for easy integration in myts.

Enjoy, Attachment 90651 and thanks for the karma!

Excellent. Your ini appears to be truncated though?

I thought they ended:
ScrollbackLines = 1000
LangSymbols = õ.÷øàèåïíôùãâëòéçìêóæñáäðîöú
LangSymbols16 = .ץקך×�טון×�׀שדגכעיחלךףזסבה×*× ž×Š×ª

Anyways I´ll go test now. : D

[qlob]

Has anyone built screen for the kindle? [is this the right place to ask?]

[twobob]

You mean the physical device? Knc1 has ripped open more than his fair share of devices I´ll be bound. I see you are 3 so not a touchscreen...

Physical defect? a piece of software I don´t know? DO you mean GM´s video drivers perhaps, they provide screenbuffer stuffing with some alacrity.

Need more clues

[qlob]

no sorry, i meant "screen" the terminal program. allows you to have multiple terminal instances in one terminal

[knc1]

Originally Posted by qlob

Has anyone built screen for the kindle? [is this the right place to ask?]

Not that I have seen reported here.

J.F. was going to consider making his terminal a "tabbed" interface.
But "Life" may have stolen all of his hobby time.

The other recent terminal application here (which runs under X11) might also be made to show multiple instances.
I don't recall reading of any such plans in that thread.

So as far I can recall - - that one (screen) is up for grabs - - go for it.

[PoP]

Originally Posted by twobob

Excellent. Your ini appears to be truncated though?

I thought they ended:
ScrollbackLines = 1000
LangSymbols = õ.÷øàèåïíôùãâëòéçìêóæñáäðîöú
LangSymbols16 = .ץקך×�טון×�׀שדגכעיחלךףזסבה×*× ž×Š×ª

Anyways I´ll go test now. : D

Sorry, I don't see where it is truncated:

Spoiler:

;;; $Id$
;;; the launchpad transparently scans keypad/fiveway/volume keystrokes
;;; until the user presses and releases the hot sequence INTRODUCER key.
;;; This enters hotkey mode, where keystrokes are captured and not passed
;;; to the Kindle up to the pressure of the TRAILER key, or a idle time
;;; of HOTINTERVAL millisecond.
;;; At this point capture is released, and captured keys are compared with
;;; existing ACTIONS. In case of a match, we execute the action, otherwise
;;; input is transferred back to the kindle.
;;; This config file is split into [sections] with generic configuration
;;; being in [SETTINGS], actions in [ACTIONS], keystroke definitions
;;; in [INKEYS], [INKEYS-DX] and [INKEYS-K3].
;;; configuration can be included with an 'include = filename' line.

[Settings]
; terminal key configuration
TermEnd = Left<
TermEsc = Left>
TermCtrl = aA
TermSym = Back ; so we can map other keys
TermShift = Shift
TermFn = Menu
TermHome = Home

;; Symbols defines the mapping for sym + one of the 28 keys:
;; qwertyuiopasdfghjklDzxcvbnm. (D is Del, . is included).
;; It needs to be a string of length 28.
Symbols = !@#$%^&*()*+#-_()&!?~$|/\"':

RefreshDelay = 50
#KpadIn = /dev/stdin
KpadIn = /dev/input/event0
FwIn = /dev/input/event1
VolIn = /dev/input/event2
KpadOut = /proc/keypad
FwOut = /proc/fiveway
VolOut = /proc/volume
SpecialIn = /var/tmp/myts.special

include = keydefs.ini
Font = ter-u32n.hex
Encoding = UTF8
FontHeight = 32
FontWidth = 16
YOffset = 40

[qlob]

Ill do my best, but ill probably fail spectacuralary [however you spell that.]

[PoP]

Originally Posted by qlob

Has anyone built screen for the kindle? [is this the right place to ask?]

Yes, in post #37 of this thread: http://www.mobileread.com/forums/sho...68#post1495668

But asking here might be slightly highjacking the subject

[twobob]

Originally Posted by PoP

Sorry, I don't see where it is truncated:

Spoiler:

;;; $Id$
;;; the launchpad transparently scans keypad/fiveway/volume keystrokes
;;; until the user presses and releases the hot sequence INTRODUCER key.
;;; This enters hotkey mode, where keystrokes are captured and not passed
;;; to the Kindle up to the pressure of the TRAILER key, or a idle time
;;; of HOTINTERVAL millisecond.
;;; At this point capture is released, and captured keys are compared with
;;; existing ACTIONS. In case of a match, we execute the action, otherwise
;;; input is transferred back to the kindle.
;;; This config file is split into [sections] with generic configuration
;;; being in [SETTINGS], actions in [ACTIONS], keystroke definitions
;;; in [INKEYS], [INKEYS-DX] and [INKEYS-K3].
;;; configuration can be included with an 'include = filename' line.

[Settings]
; terminal key configuration
TermEnd = Left<
TermEsc = Left>
TermCtrl = aA
TermSym = Back ; so we can map other keys
TermShift = Shift
TermFn = Menu
TermHome = Home

;; Symbols defines the mapping for sym + one of the 28 keys:
;; qwertyuiopasdfghjklDzxcvbnm. (D is Del, . is included).
;; It needs to be a string of length 28.
Symbols = !@#$%^&*()*+#-_()&!?~$|/\"':

RefreshDelay = 50
#KpadIn = /dev/stdin
KpadIn = /dev/input/event0
FwIn = /dev/input/event1
VolIn = /dev/input/event2
KpadOut = /proc/keypad
FwOut = /proc/fiveway
VolOut = /proc/volume
SpecialIn = /var/tmp/myts.special

include = keydefs.ini
Font = ter-u32n.hex
Encoding = UTF8
FontHeight = 32
FontWidth = 16
YOffset = 40

Spoiler:

;;; $Id$
;;; the launchpad transparently scans keypad/fiveway/volume keystrokes
;;; until the user presses and releases the hot sequence INTRODUCER key.
;;; This enters hotkey mode, where keystrokes are captured and not passed
;;; to the Kindle up to the pressure of the TRAILER key, or a idle time
;;; of HOTINTERVAL millisecond.
;;; At this point capture is released, and captured keys are compared with
;;; existing ACTIONS. In case of a match, we execute the action, otherwise
;;; input is transferred back to the kindle.
;;; This config file is split into [sections] with generic configuration
;;; being in [SETTINGS], actions in [ACTIONS], keystroke definitions
;;; in [INKEYS], [INKEYS-DX] and [INKEYS-K3].
;;; configuration can be included with an 'include = filename' line.

[Settings]
; terminal key configuration
TermEnd = Left<
TermEsc = Left>
TermCtrl = aA
TermSym = Back ; so we can map other keys
TermShift = Shift
TermFn = Menu
TermLang = Sym
TermHome = Home
TermScrollup = Right<
TermScrolldown = Right>

;; Symbols defines the mapping for sym + one of the 28 keys:
;; qwertyuiopasdfghjklDzxcvbnm. (D is Del, . is included).
;; It needs to be a string of length 28.
Symbols = !@#$%^&*()*+#-_()&!?~$|/\"':

RefreshDelay = 50
#KpadIn = /dev/stdin
KpadIn = /dev/input/event0
FwIn = /dev/input/event1
VolIn = /dev/input/event2
KpadOut = /proc/keypad
FwOut = /proc/fiveway
VolOut = /proc/volume
SpecialIn = /var/tmp/myts.special

include = keydefs.ini
Font = ter-u32n.hex
Encoding = UTF8
FontHeight = 32
FontWidth = 16
YOffset = 40

ScrollbackLines = 1000
LangSymbols = õ.÷øàèåïíôùãâëòéçìêóæñáäðîöú
LangSymbols16 = .ץקך×�טון×�׀שדגכעיחלךףזסבה×*× ž×Š×ª

Also I cant get the font to work? gah. fiddling now.

HEH: If yours is working perhaps I should truncate mine! lol

EDIT: That´s more or less straight from the myts8 above with your bits in (unworking my end might I add)

[idoit]

Originally Posted by PoP

Yes, in post #37 of this thread: http://www.mobileread.com/forums/sho...68#post1495668

But asking here might be slightly highjacking the subject

Here you can find the build for screen and much more:
http://www.fabiszewski.net/kindle-xterm/
or here.

Send your karma to baf and McArrow respectively.

[twobob]

ssh in then:

#################################################
# N O T I C E * N O T I C E * N O T I C E #
#################################################
Rootfs is mounted read-only. Invoke mntroot rw to
switch back to a writable rootfs.
#################################################
Linux kindle 2.6.26-rt-lab126 #5 Thu Sep 8 22:30:01 PDT 2011 armv6l unknown

root@kindle:root> nano /mnt/us/myts/profile (or vi for you)

export TERM=xterm
if [ -f /mnt/us/myts/.bashrc ]; then
    source /mnt/us/myts/.bashrc
fi

root@kindle:root> nano /mnt/us/myts/.bashrc (or vi)

source /mnt/us/myts/.alias
uname -a
#
export LD_LIBRARY_PATH=/mnt/us/usr/lib:/usr/lib:/lib:/mnt/us/lib
export PATH=/mnt/us/usr/local/bin:/mnt/us/usr/bin:/mnt/us/bin:/mnt/us/usr/sbin:/mnt/us/sbin:
/usr/local/bin:/usr/bin:/bin:/usr/sbin:/sbin:/mnt/us/home/root
#export LD_PRELOAD=/mnt/us/usr/lib/libz.so.1
#export SDL_VIDEODRIVER=aalib
export PERL5LIB=/mnt/us/usr/lib/perl5/5.12.4:$LD_LIBRARY_PATH:/mnt/us/usr/lib/perl5/5.12.4/
arm-unknown-linux-gnueabi

root@kindle:root> nano /mnt/us/myts/.alias (or vi)

alias ..='cd ..'
alias ls='ls -F --color'
alias ll='ls -FAlsh --color'
#
alias rm='rm -i'
alias cp='cp -i'
alias mv='mv -i'
#
alias du='du -sh'
alias df='df -h'
alias cdz='cd /mnt/us'

Hope that helps me and others remember handy tips.

Thanks to the kindle Kindlet thread, Matan, Niluje, Knc1, Gm et al.
